TOR Ports: Kira Carsen Female Player Head for K1 1.0.0

   (0 reviews)

8 Screenshots

About This File

This mod adds the head model of the Jedi Knight companion Kira Carsen from The Old Republic MMO, ported to K1 as a selectable player head for female characters. TOR uses the same base head mesh for Kira and Meetra Surik, so this was basically a two-for-one deal, given that the most difficult element is reskinning the face.

N.B. Some screenshots feature @ndix UR's KOTOR High Resolution Menus

A few notes:

  • While aligned as closely as possible, the neckline probably won't match perfectly. Expect some visible gaps on body models that don't hide the join.
  • The TOR head models use separate textures for the face, eyes, and hair. In order to allow for DS transitions, these had to be merged together (and the UVs adjusted to match). The eyes are the big loser in this. They went from having their own dedicated 256x256 texture to being shrunk down to a corner where they could be squeezed in.
  • An additional consequence of the texture merge is no normal maps, due to the hair requiring alpha masking.
  • TOR heavily relies on tint mapping textures for variation - skin tone, hair colour, eye colour, etc. Unfortunately, while the tint colours are available in the material files, the specifics of their shaders are currently unknown to me, so the best I can do is experiment with various blend modes to approximate the look. It may require some further experimentation and kludging.
  • Not even having specularity, much less the advanced (by comparison) graphical features of TOR, expect textures to look pretty flat by comparison to the originals.
  • KOTOR has a maximum bone limit per mesh of 16. This creates a problem for TOR meshes, as adding the eyelids to the face bone array pushes that to 18. I had to drop 2 bones to make it work. I chose the two nose corner bones, as they seemed the least important. I don't know what effect this may have on various facial animations though.
  • The hair meshes are currently completely rigid. Possibly I may add a danglymesh version in a future update.
  • Dark Side transitions are included, but they are relatively mild. I'm not a big fan of the zombie look.
  • In an act of ultimate laziness, the mod currently uses all the same portraits as the TSL mod. I might eventually update them to make them more K1-like.

Acknowledgements:

  • Original models and textures ported from The Old Republic MMO
  • Thanks to @bead-v for KOTORMax and MDLEdit
  • Thanks to @ndix UR for TGA2TPC
  • Thanks to zaramot on the Xentax forums for the TOR GR2 Max import script
  • Like 1



User Feedback

Recommended Comments

Are you planning on bringing the Jaesa head over to Kotor 1 as well once you get it to a 1.0 state like you said yesterday? (My apologies if I sound like a broken record!)

Share this comment


Link to comment
Share on other sites

Thank you so much for this mod, Ill admit I used this to change juhani's head model, but I still thank you none the less for this mod which allowed me to do so :)

Share this comment


Link to comment
Share on other sites

I absolutely love this mod!  <3 But I noticed when she is running/walking, the back of her neck seems to overlap with the collar of her shirt.  Is there any way to fix this?  I'm comfortable editing mdl files but at a cursory glance couldn't see any big differences between her neck geometry and one from the game.  Thanks! ^-^

Share this comment


Link to comment
Share on other sites

Hi!  I'm playing as a scout, currently wearing the Light Body Armor (it does this during conversations too).  If I wear the Heavy Combat Suit it doesn't do that, so I guess it has to do with the height of the collar?



Share this comment


Link to comment
Share on other sites

That worked perfectly, thank you! :D  No, unfortunately I'm not using K1CP, I'm afraid it would be incompatible with the other mods I downloaded quite some time ago, and I don't want to mess with Steam's default install directory.  But this should do the trick. :)  Again, thanks for this mod!  There aren't many new heads for the Kotor1 lady. ^-^
